PLC Roll Mesh Welding Machine Cold Rolled Ribbed Steel Wire

Brand Name : FZ

Model Number : DNW-25Q

Certification : CE ISO

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50 sets per month

Delivery Time : 30 days

Packaging Details : Plastic films or can be customized.

Usage : Roll mesh

Lead time : 25 days

Welding method : Pneumatic

Automation degree : Full automatic

Producton capacity : 50 Sets/Month

Voltage : 220V/380V/415V/440V

Control system : PLC

Cooling method : Water cooling

Warranty : 1 year

Contact Now

Cold Rolled Ribbed Steel Wire Roll Mesh Welding Machine

Do not use in the following places: places with corrosive liquids, dust, smoke and dangerous goods and combustible gases; places exposed to high temperature, condensation, wind and rain; places with vibration and shock. Misoperation may also cause damage to the machine.

When hoisting, must choose the appropriate hoisting tools, otherwise may cause personnel injury and machine damage.

When bolt connection, the connection must be fastened to ensure that the installation must be in place, otherwise it may cause human injury.

Item	Product type	Parameter	Remark
1	Max. welding capacity	¢ 6+6mm
2	Long wire diameter	¢3-6mm
3	Cross wire diameter	¢3-6mm
4	Long wire feeding method	In coil
5	Cross wire feeding method	In pre-cut
6	Long wire spacing	≥50mm	Mechanically adjustments
7	Cross wire spacing	≥50mm	Programming adjustments
8	Length range of wire mesh	≤60000mm	Adjustable
9	Width range of wire mesh	≤2500mm	Adjustable
10	Number of welding spot	16PCS
11	Working speed max.	40-60times/min

Welding forming mesh, the motor of Construction Full Automatically Roll Mesh Welding Machine gives the roll power, the mesh is rolled, the whole mesh is finished, one end of the Construction Full Automatically Roll Mesh Welding Machine is opened, and the other end is automatically rolled out by Construction Full Automatically Roll Mesh Welding Machine.
